Create a Figma Clone app with Flutter and Supabase Realtime

2024-01-26

35 minute read

Supabase has a low latency real-time communication feature called Broadcast. With it, you can have your clients communicate with other clients with low latencies. This is useful for creating apps with connected experiences. Flutter has a CustomPainter class, which allows developers to interact with the low-level canvas API allowing us to render virtually anything on the app. Combining these two tools allows us to create interactive apps.

In this article, I am combining the Supabase Realtime Broadcast with Flutter’s CustomPainter to create a collaborative design board app like Figma.

You can find the full code example here.

Overview of the Figma clone app

We are building an interactive design canvas app where multiple users can collaborate in real time. We will add the following features to the app:

  • Draw shapes such as circles or rectangles
  • Move those shapes around
  • Sync the cursor position and the design objects with other clients in real-time
  • Persist the state of the canvas in a Postgres database

Okay, Figma clone might be an overstatement. However, the point of this article is to demonstrate how to build a collaborative app with all the fundamental elements of a collaborative design canvas. You can take the concepts of this app, add features, refine it, and make it as sophisticated as Figma.

Setting up the app

Create a blank Flutter application

Let’s start by creating a blank Flutter app.


_10
flutter create canvas --empty --platforms=web

--empty flag creates a blank Flutter project without the initial counter template. --platforms specify which platform to support with this Flutter application. Because we are working on an app that involves cursors, we are going to focus on the web for this example, but you can certainly run the same code on other platforms as well.

Install the dependencies

We will use two dependencies for this app.

  • supabase_flutter: Used to interact with the Supabase instance for real-time communication and storing canvas data.
  • uuid: Used to generate unique identifiers for each user and canvas objects. To keep this example simple, we will not add authentication, and will just assign randomly generated UUIDs to each user.

Run the following command to add the dependencies to your app.


_10
flutter pub add supabase_flutter uuid

Setup the Supabase project

In this example, we will be using a remote Supabase instance, but if you would like to follow along with a local Supabase instance, that is fine too.

You can head to database.new to create a new Supabase project for free. It will only take a minute or two to set up your project with a fully-fledged Postgres database.

Once your project is ready, run the following SQL from the SQL editor of your dashboard to set up the table and RLS policies for this app. To keep this article simple, we will not implement auth, so the policies you see are fairly simple.


_10
create table canvas_objects (
_10
id uuid primary key default gen_random_uuid() not null,
_10
"object" jsonb not null,
_10
created_at timestamp with time zone default timezone('utc'::text, now()) not null
_10
);
_10
_10
alter table canvas_objects enable row level security;
_10
create policy select_canvas_objects on canvas_objects as permissive for select to anon using (true);
_10
create policy insert_canvas_objects on canvas_objects as permissive for insert to anon with check (true);
_10
create policy update_canvas_objects on canvas_objects as permissive for update to anon using (true);

Building the Figma clone app

The app that we will build will have the following structure.


_10
lib/
_10
├── canvas/ # A folder containing the main canvas-related files.
_10
│ ├── canvas_object.dart # Data model definitions.
_10
│ ├── canvas_page.dart # The canvas page widget.
_10
│ └── canvas_painter.dart # Custom painter definitions.
_10
├── utils/
_10
│ └── constants.dart # A file to hold Supabase Realtime specific constants
_10
└── main.dart # Entry point of the app

Step1: Initialize Supabase

Open the lib/main.dart file and add the following. You should replace the credentials with your own from the Supabase dashboard under settings > API. You should see an error with the import of the canvas_page.dart file, but we will create it momentarily.


_27
import 'package:canvas/canvas/canvas_page.dart';
_27
import 'package:flutter/material.dart';
_27
import 'package:supabase_flutter/supabase_flutter.dart';
_27
_27
void main() async {
_27
Supabase.initialize(
_27
// TODO: Replace the credentials with your own
_27
url: 'YOUR_SUPABASE_URL',
_27
anonKey: 'YOUR_SUPABASE_ANON_KEY',
_27
);
_27
runApp(const MyApp());
_27
}
_27
_27
final supabase = Supabase.instance.client;
_27
_27
class MyApp extends StatelessWidget {
_27
const MyApp({super.key});
_27
_27
@override
_27
Widget build(BuildContext context) {
_27
return const MaterialApp(
_27
title: 'Figma Clone',
_27
debugShowCheckedModeBanner: false,
_27
home: CanvasPage(),
_27
);
_27
}
_27
}

Step 2: Create the constants file

It is nice to organize the app’s constants in a file. Create lib/utils/constants.dart file and add the following. These values will later be used when we are setting up Supabase Realtime listeners.


_10
abstract class Constants {
_10
/// Name of the Realtime channel
_10
static const String channelName = 'canvas';
_10
_10
/// Name of the broadcast event
_10
static const String broadcastEventName = 'canvas';
_10
}

Step 3: Create the data model

We will need to create data models for each of the following:

  • The cursor position of the user.
  • The objects we can draw on the canvas. Includes:
    • Circle
    • Rectangle

Create lib/canvas/canvas_object.dart file. The file is a bit long, so I will break it down in each component below. Add all of the code into the canvas_object.dart file as we step through them.

At the top of the file, we have an extension method to generate random colors. One of the methods generates a random color, which will be used to set the color of a newly created object, and the other generates a random with a seed of a UUID, which will be used to determine the user’s cursor color.


_19
import 'dart:convert';
_19
import 'dart:math';
_19
import 'dart:ui';
_19
_19
import 'package:uuid/uuid.dart';
_19
_19
/// Handy extension method to create random colors
_19
extension RandomColor on Color {
_19
static Color getRandom() {
_19
return Color((Random().nextDouble() * 0xFFFFFF).toInt()).withOpacity(1.0);
_19
}
_19
_19
/// Quick and dirty method to create a random color from the userID
_19
static Color getRandomFromId(String id) {
_19
final seed = utf8.encode(id).reduce((value, element) => value + element);
_19
return Color((Random(seed).nextDouble() * 0xFFFFFF).toInt())
_19
.withOpacity(1.0);
_19
}
_19
}

We then have the SyncedObject class. SyncedObject class is the base class for anything that will be synced in real time, this includes both the cursor and the objects. It has an id property, which will be UUID, and it has toJson method, which is required to pass the object information over Supabase’s broadcast feature.


_22
/// Objects that are being synced in realtime over broadcast
_22
///
_22
/// Includes mouse cursor and design objects
_22
abstract class SyncedObject {
_22
/// UUID unique identifier of the object
_22
final String id;
_22
_22
factory SyncedObject.fromJson(Map<String, dynamic> json) {
_22
final objectType = json['object_type'];
_22
if (objectType == UserCursor.type) {
_22
return UserCursor.fromJson(json);
_22
} else {
_22
return CanvasObject.fromJson(json);
_22
}
_22
}
_22
_22
SyncedObject({
_22
required this.id,
_22
});
_22
_22
Map<String, dynamic> toJson();
_22
}

Now to sync the user’s cursor with other clients, we have the UserCursor class. It inherits the SyncedObject class and has JSON parsing implemented.


_29
/// Data model for the cursors displayed on the canvas.
_29
class UserCursor extends SyncedObject {
_29
static String type = 'cursor';
_29
_29
final Offset position;
_29
final Color color;
_29
_29
UserCursor({
_29
required super.id,
_29
required this.position,
_29
}) : color = RandomColor.getRandomFromId(id);
_29
_29
UserCursor.fromJson(Map<String, dynamic> json)
_29
: position = Offset(json['position']['x'], json['position']['y']),
_29
color = RandomColor.getRandomFromId(json['id']),
_29
super(id: json['id']);
_29
_29
@override
_29
Map<String, dynamic> toJson() {
_29
return {
_29
'object_type': type,
_29
'id': id,
_29
'position': {
_29
'x': position.dx,
_29
'y': position.dy,
_29
}
_29
};
_29
}
_29
}

There is an additional set of data that we want to sync in real-time, and that is the individual shapes within the canvas. We create the CanvasObject abstract class, which is the base class for any shapes within the canvas. This class extends the SyncedObject because we want to sync it to other clients. In addition to the id property, we have a color property, because every shape needs a color. We also have a few methods.

  • intersectsWith() takes a point within the canvas and returns whether the point intersects with the shape or not. This is used when grabbing the shape on the canvas.
  • copyWith() is a standard method to create a copy of the instance.
  • move() is a method to create a version of the instance that is moved by delta. This will be used when the shape is being dragged on canvas.

_27
/// Base model for any design objects displayed on the canvas.
_27
abstract class CanvasObject extends SyncedObject {
_27
final Color color;
_27
_27
CanvasObject({
_27
required super.id,
_27
required this.color,
_27
});
_27
_27
factory CanvasObject.fromJson(Map<String, dynamic> json) {
_27
if (json['object_type'] == CanvasCircle.type) {
_27
return CanvasCircle.fromJson(json);
_27
} else if (json['object_type'] == CanvasRectangle.type) {
_27
return CanvasRectangle.fromJson(json);
_27
} else {
_27
throw UnimplementedError('Unknown object_type: ${json['object_type']}');
_27
}
_27
}
_27
_27
/// Whether or not the object intersects with the given point.
_27
bool intersectsWith(Offset point);
_27
_27
CanvasObject copyWith();
_27
_27
/// Moves the object to a new position
_27
CanvasObject move(Offset delta);
_27
}

Now that we have the base class for the canvas objects, let’s define the actual shapes we will support in this application. Each object will inherit CanvasObject and will have additional properties like center and radius for the circle.

In this article, we are only supporting circles and rectangles, but you can easily expand this and add support for other shapes.


_141
/// Circle displayed on the canvas.
_141
class Circle extends CanvasObject {
_141
static String type = 'circle';
_141
_141
final Offset center;
_141
final double radius;
_141
_141
Circle({
_141
required super.id,
_141
required super.color,
_141
required this.radius,
_141
required this.center,
_141
});
_141
_141
Circle.fromJson(Map<String, dynamic> json)
_141
: radius = json['radius'],
_141
center = Offset(json['center']['x'], json['center']['y']),
_141
super(id: json['id'], color: Color(json['color']));
_141
_141
/// Constructor to be used when first starting to draw the object on the canvas
_141
Circle.createNew(this.center)
_141
: radius = 0,
_141
super(id: const Uuid().v4(), color: RandomColor.getRandom());
_141
_141
@override
_141
Map<String, dynamic> toJson() {
_141
return {
_141
'object_type': type,
_141
'id': id,
_141
'color': color.value,
_141
'center': {
_141
'x': center.dx,
_141
'y': center.dy,
_141
},
_141
'radius': radius,
_141
};
_141
}
_141
_141
@override
_141
Circle copyWith({
_141
double? radius,
_141
Offset? center,
_141
Color? color,
_141
}) {
_141
return Circle(
_141
radius: radius ?? this.radius,
_141
center: center ?? this.center,
_141
id: id,
_141
color: color ?? this.color,
_141
);
_141
}
_141
_141
@override
_141
bool intersectsWith(Offset point) {
_141
final centerToPointerDistance = (point - center).distance;
_141
return radius > centerToPointerDistance;
_141
}
_141
_141
@override
_141
Circle move(Offset delta) {
_141
return copyWith(center: center + delta);
_141
}
_141
}
_141
_141
/// Rectangle displayed on the canvas.
_141
class Rectangle extends CanvasObject {
_141
static String type = 'rectangle';
_141
_141
final Offset topLeft;
_141
final Offset bottomRight;
_141
_141
Rectangle({
_141
required super.id,
_141
required super.color,
_141
required this.topLeft,
_141
required this.bottomRight,
_141
});
_141
_141
Rectangle.fromJson(Map<String, dynamic> json)
_141
: bottomRight =
_141
Offset(json['bottom_right']['x'], json['bottom_right']['y']),
_141
topLeft = Offset(json['top_left']['x'], json['top_left']['y']),
_141
super(id: json['id'], color: Color(json['color']));
_141
_141
/// Constructor to be used when first starting to draw the object on the canvas
_141
Rectangle.createNew(Offset startingPoint)
_141
: topLeft = startingPoint,
_141
bottomRight = startingPoint,
_141
super(color: RandomColor.getRandom(), id: const Uuid().v4());
_141
_141
@override
_141
Map<String, dynamic> toJson() {
_141
return {
_141
'object_type': type,
_141
'id': id,
_141
'color': color.value,
_141
'top_left': {
_141
'x': topLeft.dx,
_141
'y': topLeft.dy,
_141
},
_141
'bottom_right': {
_141
'x': bottomRight.dx,
_141
'y': bottomRight.dy,
_141
},
_141
};
_141
}
_141
_141
@override
_141
Rectangle copyWith({
_141
Offset? topLeft,
_141
Offset? bottomRight,
_141
Color? color,
_141
}) {
_141
return Rectangle(
_141
topLeft: topLeft ?? this.topLeft,
_141
id: id,
_141
bottomRight: bottomRight ?? this.bottomRight,
_141
color: color ?? this.color,
_141
);
_141
}
_141
_141
@override
_141
bool intersectsWith(Offset point) {
_141
final minX = min(topLeft.dx, bottomRight.dx);
_141
final maxX = max(topLeft.dx, bottomRight.dx);
_141
final minY = min(topLeft.dy, bottomRight.dy);
_141
final maxY = max(topLeft.dy, bottomRight.dy);
_141
return minX < point.dx &&
_141
point.dx < maxX &&
_141
minY < point.dy &&
_141
point.dy < maxY;
_141
}
_141
_141
@override
_141
Rectangle move(Offset delta) {
_141
return copyWith(
_141
topLeft: topLeft + delta,
_141
bottomRight: bottomRight + delta,
_141
);
_141
}
_141
}

That is it for the canvas_object.dart file.

Step 4: Create the custom painter

CustomPainter is a low-level API to interact with the canvas within a Flutter application. We will create our own CustomPainter that takes the cursor positions and the objects within the app and draws them on a canvas.

Create lib/canvas/canvas_painter.dart file and add the following.


_48
import 'package:canvas/canvas/canvas_object.dart';
_48
import 'package:flutter/material.dart';
_48
_48
class CanvasPainter extends CustomPainter {
_48
final Map<String, UserCursor> userCursors;
_48
final Map<String, CanvasObject> canvasObjects;
_48
_48
CanvasPainter({
_48
required this.userCursors,
_48
required this.canvasObjects,
_48
});
_48
_48
@override
_48
void paint(Canvas canvas, Size size) {
_48
// Draw each canvas objects
_48
for (final canvasObject in canvasObjects.values) {
_48
if (canvasObject is Circle) {
_48
final position = canvasObject.center;
_48
final radius = canvasObject.radius;
_48
canvas.drawCircle(
_48
position, radius, Paint()..color = canvasObject.color);
_48
} else if (canvasObject is Rectangle) {
_48
final position = canvasObject.topLeft;
_48
final bottomRight = canvasObject.bottomRight;
_48
canvas.drawRect(
_48
Rect.fromLTRB(
_48
position.dx, position.dy, bottomRight.dx, bottomRight.dy),
_48
Paint()..color = canvasObject.color);
_48
}
_48
}
_48
_48
// Draw the cursors
_48
for (final userCursor in userCursors.values) {
_48
final position = userCursor.position;
_48
canvas.drawPath(
_48
Path()
_48
..moveTo(position.dx, position.dy)
_48
..lineTo(position.dx + 14.29, position.dy + 44.84)
_48
..lineTo(position.dx + 20.35, position.dy + 25.93)
_48
..lineTo(position.dx + 39.85, position.dy + 24.51)
_48
..lineTo(position.dx, position.dy),
_48
Paint()..color = userCursor.color);
_48
}
_48
}
_48
_48
@override
_48
bool shouldRepaint(oldPainter) => true;
_48
}

userCursors and canvasObjects represent the cursors and the objects within the canvas respectively. The key of the Map is the UUID unique identifiers.

The paint() method is where the drawing on the canvas happens. It first loops through the objects and draws them on the canvas. Each shape has its drawing method, so we will check the type of the object in each loop and apply the respective drawing method.

Once we have all the objects drawn, we draw the cursors. The reason why we draw the cursors after the objects is because within a custom painter, whatever is drawn later draws over the previously drawn objects. Because we do not want the cursors to be hidden behind the objects, we draw all the cursors after all of the objects are done being drawn.

shouldRepaint() defines whether we want the canvas to be repainted when the CustomPainter receives a new set of properties. In our case, we want to redraw the painter whenever we receive a new set of properties, so we always return true.

Step 5: Create the canvas page

Now that we have the data models and our custom painter ready, it is time to put everything together. We will create a canvas page, the only page of this app, which allows users to draw shapes and move those shapes around while keeping the states in sync with other users.

Create lib/canvas/canvas_page.dart file. Add all of the code shown within this step into canvas_page.dart. Start by adding all the necessary imports for this app.


_10
import 'dart:math';
_10
_10
import 'package:canvas/canvas/canvas_object.dart';
_10
import 'package:canvas/canvas/canvas_painter.dart';
_10
import 'package:canvas/main.dart';
_10
import 'package:canvas/utils/constants.dart';
_10
import 'package:flutter/material.dart';
_10
import 'package:supabase_flutter/supabase_flutter.dart';
_10
import 'package:uuid/uuid.dart';

We can then create an enum to represent the three different actions we can perform in this app, pointer for moving objects around, circle for drawing circles, and rectangle for drawing rectangles.


_16
/// Different input modes users can perform
_16
enum _DrawMode {
_16
/// Mode to move around existing objects
_16
pointer(iconData: Icons.pan_tool_alt),
_16
_16
/// Mode to draw circles
_16
circle(iconData: Icons.circle_outlined),
_16
_16
/// Mode to draw rectangles
_16
rectangle(iconData: Icons.rectangle_outlined);
_16
_16
const _DrawMode({required this.iconData});
_16
_16
/// Icon used in the IconButton to toggle the mode
_16
final IconData iconData;
_16
}

Finally, we can get to the meat of the app, creating the CanvasPage widget. Create an empty StatefulWidget with a blank Scaffold. We will be adding properties, methods, and widgets to it.


_19
_19
/// Interactive art board page to draw and collaborate with other users.
_19
class CanvasPage extends StatefulWidget {
_19
const CanvasPage({super.key});
_19
_19
@override
_19
State<CanvasPage> createState() => _CanvasPageState();
_19
}
_19
_19
class _CanvasPageState extends State<CanvasPage> {
_19
// TODO: Add properties
_19
_19
// TODO: Add methods
_19
_19
@override
_19
Widget build(BuildContext context) {
_19
return Scaffold();
_19
}
_19
}

First, we can define all of the properties we need for this widget. _userCursors and _canvasObjects will hold the cursors and canvas objects the app receives from the real-time listener. _canvasChanel is the gateway for the client to communicate with other clients using Supabase Realtime. We will later implement the logic to send and receive information about the canvas. Then there are a few states that will be used when we implement the drawing on the canvas.


_32
class _CanvasPageState extends State<CanvasPage> {
_32
/// Holds the cursor information of other users
_32
final Map<String, UserCursor> _userCursors = {};
_32
_32
/// Holds the list of objects drawn on the canvas
_32
final Map<String, CanvasObject> _canvasObjects = {};
_32
_32
/// Supabase Realtime channel to communicate to other clients
_32
late final RealtimeChannel _canvasChanel;
_32
_32
/// Randomly generated UUID for the user
_32
late final String _myId;
_32
_32
/// Whether the user is using the pointer to move things around, or in drawing mode.
_32
_DrawMode _currentMode = _DrawMode.pointer;
_32
_32
/// A single Canvas object that is being drawn by the user if any.
_32
String? _currentlyDrawingObjectId;
_32
_32
/// The point where the pan started
_32
Offset? _panStartPoint;
_32
_32
/// Cursor position of the user.
_32
Offset _cursorPosition = const Offset(0, 0);
_32
_32
// TODO: Add methods
_32
_32
@override
_32
Widget build(BuildContext context) {
_32
return Scaffold();
_32
}
_32
}

Now that we have the properties defined, we can run some initialization code to set up the scene. There are a few things we are doing in this initialization step.

One, assigning a randomly generated UUID to the user. Two, setting up the real-time listener for Supabase. We are listening to Realtime Broadcast events, which are low-latency real-time communication mechanisms that Supabase offers. Within the callback of the broadcast event, we obtain the cursor and object information sent from other clients and set the state accordingly. And three, we load the initial state of the canvas from the database and set it as the initial state of the widget.

Now that the app has been initialized, we are ready to implement the logic of the user drawing and interacting with the canvas.


_48
class _CanvasPageState extends State<CanvasPage> {
_48
...
_48
_48
@override
_48
void initState() {
_48
super.initState();
_48
_initialize();
_48
}
_48
_48
Future<void> _initialize() async {
_48
// Generate a random UUID for the user.
_48
// We could replace this with Supabase auth user ID if we want to make it
_48
// more like Figma.
_48
_myId = const Uuid().v4();
_48
_48
// Start listening to broadcast messages to display other users' cursors and objects.
_48
_canvasChanel = supabase
_48
.channel(Constants.channelName)
_48
.onBroadcast(
_48
event: Constants.broadcastEventName,
_48
callback: (payload) {
_48
final cursor = UserCursor.fromJson(payload['cursor']);
_48
_userCursors[cursor.id] = cursor;
_48
_48
if (payload['object'] != null) {
_48
final object = CanvasObject.fromJson(payload['object']);
_48
_canvasObjects[object.id] = object;
_48
}
_48
setState(() {});
_48
})
_48
.subscribe();
_48
_48
final initialData = await supabase
_48
.from('canvas_objects')
_48
.select()
_48
.order('created_at', ascending: true);
_48
for (final canvasObjectData in initialData) {
_48
final canvasObject = CanvasObject.fromJson(canvasObjectData['object']);
_48
_canvasObjects[canvasObject.id] = canvasObject;
_48
}
_48
setState(() {});
_48
}
_48
_48
@override
_48
Widget build(BuildContext context) {
_48
return Scaffold();
_48
}
_48
}

We have three methods triggered by user actions, _onPanDown(), _onPanUpdate(), and _onPanEnd(), and a method to sync the user action with other clients _syncCanvasObject().

What the three pan methods do could be two things, either to draw the object or to move the object.

When drawing an object, on pan down it will add the object to the canvas with size 0, essentially a point. As the user drags the mouse, the pan update method is called which gives the object some size while syncing the object to other clients along the way.

When the user is in pointer mode, the pan-down method first determines if there is an object under where the user’s pointer currently is located. If there is an object, it holds the object’s id as the widget’s state. As the user drags the screen, the position of the object is moved the same amount the user’s cursor moves, while syncing the object’s information through broadcast along the way.

In both cases, when the user is done dragging, the pan end is called which does some clean-ups of the local state and stores the object information in the database to store the canvas data permanently.


_122
class _CanvasPageState extends State<CanvasPage> {
_122
...
_122
_122
/// Syncs the user's cursor position and the currently drawing object with
_122
/// other users.
_122
Future<void> _syncCanvasObject(Offset cursorPosition) {
_122
final myCursor = UserCursor(
_122
position: cursorPosition,
_122
id: _myId,
_122
);
_122
return _canvasChanel.sendBroadcastMessage(
_122
event: Constants.broadcastEventName,
_122
payload: {
_122
'cursor': myCursor.toJson(),
_122
if (_currentlyDrawingObjectId != null)
_122
'object': _canvasObjects[_currentlyDrawingObjectId]?.toJson(),
_122
},
_122
);
_122
}
_122
_122
/// Called when pan starts.
_122
///
_122
/// For [_DrawMode.pointer], it will find the first object under the cursor.
_122
///
_122
/// For other draw modes, it will start drawing the respective canvas objects.
_122
void _onPanDown(DragDownDetails details) {
_122
switch (_currentMode) {
_122
case _DrawMode.pointer:
_122
// Loop through the canvas objects to find if there are any
_122
// that intersects with the current mouse position.
_122
for (final canvasObject in _canvasObjects.values.toList().reversed) {
_122
if (canvasObject.intersectsWith(details.globalPosition)) {
_122
_currentlyDrawingObjectId = canvasObject.id;
_122
break;
_122
}
_122
}
_122
break;
_122
case _DrawMode.circle:
_122
final newObject = Circle.createNew(details.globalPosition);
_122
_canvasObjects[newObject.id] = newObject;
_122
_currentlyDrawingObjectId = newObject.id;
_122
break;
_122
case _DrawMode.rectangle:
_122
final newObject = Rectangle.createNew(details.globalPosition);
_122
_canvasObjects[newObject.id] = newObject;
_122
_currentlyDrawingObjectId = newObject.id;
_122
break;
_122
}
_122
_cursorPosition = details.globalPosition;
_122
_panStartPoint = details.globalPosition;
_122
setState(() {});
_122
}
_122
_122
/// Called when the user clicks and drags the canvas.
_122
///
_122
/// Performs different actions depending on the current mode.
_122
void _onPanUpdate(DragUpdateDetails details) {
_122
switch (_currentMode) {
_122
// Moves the object to [details.delta] amount.
_122
case _DrawMode.pointer:
_122
if (_currentlyDrawingObjectId != null) {
_122
_canvasObjects[_currentlyDrawingObjectId!] =
_122
_canvasObjects[_currentlyDrawingObjectId!]!.move(details.delta);
_122
}
_122
break;
_122
_122
// Updates the size of the Circle
_122
case _DrawMode.circle:
_122
final currentlyDrawingCircle =
_122
_canvasObjects[_currentlyDrawingObjectId!]! as Circle;
_122
_canvasObjects[_currentlyDrawingObjectId!] =
_122
currentlyDrawingCircle.copyWith(
_122
center: (details.globalPosition + _panStartPoint!) / 2,
_122
radius: min((details.globalPosition.dx - _panStartPoint!.dx).abs(),
_122
(details.globalPosition.dy - _panStartPoint!.dy).abs()) /
_122
2,
_122
);
_122
break;
_122
_122
// Updates the size of the rectangle
_122
case _DrawMode.rectangle:
_122
_canvasObjects[_currentlyDrawingObjectId!] =
_122
(_canvasObjects[_currentlyDrawingObjectId!] as Rectangle).copyWith(
_122
bottomRight: details.globalPosition,
_122
);
_122
break;
_122
}
_122
_122
if (_currentlyDrawingObjectId != null) {
_122
setState(() {});
_122
}
_122
_cursorPosition = details.globalPosition;
_122
_syncCanvasObject(_cursorPosition);
_122
}
_122
_122
void onPanEnd(DragEndDetails _) async {
_122
if (_currentlyDrawingObjectId != null) {
_122
_syncCanvasObject(_cursorPosition);
_122
}
_122
_122
final drawnObjectId = _currentlyDrawingObjectId;
_122
_122
setState(() {
_122
_panStartPoint = null;
_122
_currentlyDrawingObjectId = null;
_122
});
_122
_122
// Save whatever was drawn to Supabase DB
_122
if (drawnObjectId == null) {
_122
return;
_122
}
_122
await supabase.from('canvas_objects').upsert({
_122
'id': drawnObjectId,
_122
'object': _canvasObjects[drawnObjectId]!.toJson(),
_122
});
_122
}
_122
_122
@override
_122
Widget build(BuildContext context) {
_122
return Scaffold();
_122
}
_122
}

With all the properties and methods defined, we can proceed to add content to the build method. The entire region is covered in MouseRegion, which is used to get the cursor position and share it with other clients. Within the mouse region, we have the GestureDetector and the three buttons representing each action. Because the heavy lifting was done in the methods we have already defined, the build method is fairly simple.


_51
class _CanvasPageState extends State<CanvasPage> {
_51
...
_51
_51
@override
_51
Widget build(BuildContext context) {
_51
return Scaffold(
_51
body: MouseRegion(
_51
onHover: (event) {
_51
_syncCanvasObject(event.position);
_51
},
_51
child: Stack(
_51
children: [
_51
// The main canvas
_51
GestureDetector(
_51
onPanDown: _onPanDown,
_51
onPanUpdate: _onPanUpdate,
_51
onPanEnd: onPanEnd,
_51
child: CustomPaint(
_51
size: MediaQuery.of(context).size,
_51
painter: CanvasPainter(
_51
userCursors: _userCursors,
_51
canvasObjects: _canvasObjects,
_51
),
_51
),
_51
),
_51
_51
// Buttons to change the current mode.
_51
Positioned(
_51
top: 0,
_51
left: 0,
_51
child: Row(
_51
children: _DrawMode.values
_51
.map((mode) => IconButton(
_51
iconSize: 48,
_51
onPressed: () {
_51
setState(() {
_51
_currentMode = mode;
_51
});
_51
},
_51
icon: Icon(mode.iconData),
_51
color: _currentMode == mode ? Colors.green : null,
_51
))
_51
.toList(),
_51
),
_51
),
_51
],
_51
),
_51
),
_51
);
_51
}
_51
}

Step 6: Run the application

At this point, we have implemented everything we need to create a collaborative design canvas. Run the app with flutter run and run it in your browser. There is currently a bug in Flutter where MouseRegion cannot detect the position of a cursor in two different Chrome windows at the same time, so open it in two different browsers like Chrome and Safari, and enjoy interacting with your design elements in real time.

Conclusion

In this article, we learned how we can combine the Supabase Realtime Broadcast feature with Flutter’s CustomPainter to create a collaborative design app. We learned how to implement real-time communication between multiple clients using the Broadcast feature, and how we can broadcast the shape and cursor data to other connected clients in real-time.

This article only used circles and rectangles to keep things simple, but you can easily add support for other types of objects like texts or arrows just by extending the CanvasObject class to make the app more like Figma. Another fun way to expand this app would be to add authentication using Supabase Auth so that we can add proper authorizations. Adding an image upload feature using Supabase Storage would certainly open up more creative options for the app.

Resources

Share this article

Build in a weekend, scale to millions
